Daikin FVXS35FV1A User Manual

MODELSFVXS25FV1A FVXS50FV1AFVXS35FV1ADAIKIN ROOM AIR CONDITIONEROperation Manual00_CV_3P191290-2A.fm Page 1 Friday, January 12, 2007 11:22 AM

9 Turn the breaker ON• Turning ON the breaker closes the flap. (This is a normal procedure.)NOTE Tips for saving energy• Be careful not to cool (heat

10OPERATIONAUTO · DRY · COOL · HEAT · FAN OperationThe air conditioner operates with the operation mode of your choice. From the next time on, the air

11 To change the air flow rate setting5. Press “FAN setting button”.• Indoor unit quiet operationWhen the air flow is set to “ ”, the noise from the

12Adjusting the Air Flow DirectionYou can adjust the air flow direction to increase your comfort. To adjust the horizontal blade (flap)1. Press “SWIN

13 Air flow selection• Make air flow selection according to what suits you.When setting the air flow selection switch to .• Air conditioner automati

14POWERFUL OperationPOWERFUL operation quickly maximizes the cooling (heating) effect in any operation mode. You can get the maximum capacity. To st

15OUTDOOR UNIT QUIET OperationOUTDOOR UNIT QUIET operation lowers the noise level of the outdoor unit by changing the frequency and fan speed on the o

16ECONO OperationECONO operation is a function which enables efficient operation by lowering the maximum power consumption value. To start ECONO ope

17TIMER OperationTimer functions are useful for automatically switching the air conditioner on or off at night or in the morning. You can also use OFF

18TIMER Operation To use ON TIMER operation • Check that the clock is correct. If not, set the clock to the present time. (page 8.) 1. Press “ON TIME

1CONTENTSREAD BEFORE OPERATIONSafety precautions ... 2Names of parts...

19WEEKLY TIMER OperationUp to 4 timer settings can be saved for each day of the week. To use WEEKLY TIMER operation•Make sure the day of the week and

20WEEKLY TIMER Operation7. Press “NEXT button”. • The time will be set. • “ ” and the temperature blink. 8. Press “SELECT button” to select the desire

21 To cancel WEEKLY TIMER operation 11.Press “WEEKLY button” to deactivate the WEEKLY operation.• The “ ” will disappear from the display.• The TIMER

22WEEKLY TIMER Operation Confirming a reservation • The reservation can be confirmed.1. Press “ button”.• The day of the week and the reservation n

23 Setting WEEKLY TIMER using copy mode •A reservation made once can be easily copied and the same settings used for another day of the week. 1. Pres

24Note for Multi System〈〈 What is a “Multi System”? 〉〉This system has one outdoor unit connected to multiple indoor units. Selecting the operation mod

25 Priority Room SettingThe Priority Room Setting requires initial programming during installation. Please consult your retailer or dealer for assist

26CARECare and CleaningCAUTION Indoor unit, Outdoor unit and Remote controller 1. Wipe them with dry soft cloth. Front panel 1. Open the front pa

27 1. Open the front panel. (page 26.) 2. Remove the air filter.• Press the claws on the right and left of the air filter down slightly, then pull upw

28NOTECheck Before a long idle period1. Operate the “FAN only” for several hours on a fine day to dry out the inside.• Press “MODE” button and select

2READ BEFORE OPERATIONSafety precautions• Keep this manual where the operator can easily find them.• Read this manual attentively before starting up t

29TROUBLE SHOOTINGTrouble ShootingThe following cases are not air conditioner troubles but have some reasons. You may just continue using it.These cas

30Please check again before calling a repair person.Check again.Case CheckThe air conditioner does not operate.(OPERATION lamp is off.)• Hasn’t a brea

31WARNING When an abnormality (such as a burning smell) occurs, stop operation and turn the breaker OFF.Continued operation in an abnormal condition

32MEMO01_EN_3P191290-2A.fm Page 32 Friday, January 12, 2007 11:59 AM

(0701)HT3P191290-2AM06B130ATwo-dimensional bar code is a code for manufacturing.00_CV_3P191290-2A.fm Page 2 Friday, January 12, 2007 11:22 AM

3•Do not place appliances which produce open fire in places exposed to the air flow from the unit or under the indoor unit. It may cause incomplete co

4Names of parts Indoor Unit Opening the Front PanelHow to open the front panel: (page 26.) CAUTION Before opening the front panel, be sure to stop

5 Outdoor Unit Indoor Unit1. Titanium Apatite Photocatalytic Air-Purifying Filter:• These filters are attached to the inside of the air filters.2. A

6 Remote Controller 1. Signal transmitter:• It sends signals to the indoor unit.2. Display:• It displays the current settings. (In this illustration,

7Preparation Before Operation To set the batteries 1. Slide the front cover to take it off.2. Set two dry batteries (LR03·AAA).3. Set the front cover

8Preparation Before Operation To set the clock 1. Press “CLOCK button”.is displayed.and blinks.2. Press “SELECT button” to set the current day of the
